Daily (Pre-Start)
Oil (XHT3000 diesel): Check dipstick; use CF-15W40.
Fuel: Verify level, bleed air on diesel if needed.
Undercarriage: Track cracks/tension (20–30mm sag), tire pressure.
Hydraulic: Reservoir level, look for leaks.
Controls: Test lift, rotate, travel.
Periodic Service
Air Filter: Clean/blow every 50h in dusty sites; replace when discolored.
Hydraulic Oil: First change at 100h, then every 500h; use AW46 anti-wear fluid.
Greasing: Weekly on all pivot grease nipples until fresh grease purges.
Track Tension: Adjust monthly.
Common Issues
Symptom | Possible Cause | Remedy |
|---|---|---|
Hard Start | No fuel / clogged filter / fouled plug / weak battery | Refuel / clean filter / clean plug / charge |
Slow/No Lift | Low oil / overheated / relief valve mis-set / internal leak | Top-up / cool / adjust / reseal |
De-tracking | Loose track / debris jammed / worn sprocket | Tension / clear / replace |
Weak Travel | Slipping clutch / worn pump | Adjust cable / inspect pump |
Storage & Preservation
Wash off mud → wipe dry → grease exposed pivots → store indoors → disconnect battery & trickle-charge.
Conclusion
Follow this regimen and your Xinghang dumper will reliably serve 10+ years. Our after-sales team is ready to assist. Contact us for further support.
